Capacitive Sensor Series
XSZ M12 Capacitive Proximity Sensor
Ultimate versatility for diverse materials. The XSZ M12 Capacitive Proximity Sensor reliably detects both metallic and non-metallic objects, including plastics, wood, and liquids. Featuring an adjustable sensitivity potentiometer and a standard M12 housing, it offers unmatched performance for complex material tracking and liquid level control.
Key Performance Advantages
Universal Material Detection
Goes beyond standard inductive sensors by detecting conductors and dielectrics alike. Easily identify plastic components, stone, wood, and even sense liquid levels through non-metallic container walls.
Adjustable Sensitivity
Equipped with a built-in single direction knob (potentiometer), allowing you to conveniently fine-tune the sensing distance (up to 5mm) to match the specific dielectric constant of the target material.
Seamless M12 Integration
Housed in a universally compatible M12 threaded cylinder with IP65 protection. It supports a robust 200mA load and features instantaneous overvoltage protection for reliable industrial use.
Comprehensive Technical Specifications
| Specification | M12 Flush Mount | M12 Non-Flush Mount |
|---|---|---|
| Sensing Distance | 0 – 2 mm (Adjustable) | 0 – 5 mm (Adjustable) |
| Standard Sensing Object | Grounded metal plate 50 × 50 × 1 mm | |
| Detectable Object | Conductors and dielectrics (Metal, plastic, liquid, stone, wood, glass, etc.) | |
| Sensitivity Adjustment | Single direction knob (Potentiometer) | |
| Response Frequency | 100 Hz | |
| Operating Voltage Range | DC 12 to 24 VDC ±10%, ripple (p-p) Max. | |
| Load Current (Output) | 200 mA Max. (Residual Voltage: 1.5V Max.) | |
| Current Consumption | 15 mA Max. | |
| Control Output | NPN / PNP | NO / NC available | |
| Protection Circuits | Reversed power supply polarity protection, Instantaneous overvoltage protection | |
| Degree of Protection | IP 65 (IEC specification) | |
| Environmental Specs | Operating Temp: -25 to +70°C | Humidity: 35 to 85% RH | |
Wiring & Circuit Diagram
Please consult the wiring diagrams below to securely integrate the NPN/PNP capacitive proximity switch into your industrial control panel.
Ideal Industrial Applications
Accurately detect liquid levels (water, oil, chemicals) through glass or plastic container walls.
Reliably count or verify the presence of plastic parts, cardboard boxes, and non-metallic packages on conveyor lines.
Perfect for detecting the fill level of powders, grains, or wooden pellets in storage hoppers.
Versatile Detection for Any Material
Connect with our XSZ technical experts to integrate our highly flexible M12 capacitive proximity sensors into your automated systems.
Zhejiang Xinsenzheng Automation Co., Ltd. – PRECISION & INNOVATION
