Metal PNP Photoelectric Detection
CDD-11P Metal Photoelectric Sensor
A compact metal sensor for close-range industrial detection. The CDD-11P combines a 10 cm sensing distance, 10 to 30 VDC operation and DC three-wire PNP output for reliable machine presence and position feedback.
Robust PNP Detection for Industrial Equipment
The CDD-11P brings PNP output capability to close-range sensing tasks where a metal housing and direct cable connection are preferred. Its compact form is suitable for presence detection, simple positioning and process confirmation in machinery and automation fixtures.
- 10 cm sensing range supports local presence and position checks
- PNP output suits compatible sourcing-input PLC circuits
- Metal housing supports robust installation on industrial equipment
- 10 to 30 VDC operation fits common DC control systems
Built Around Practical Control Integration
01 / PNP OUTPUTPLC Integration
Use the PNP output with compatible sourcing-input PLC or controller circuits.
02 / CLOSE RANGE10 cm Detection
A practical distance for compact fixtures, guides and local machine detection zones.
03 / METAL BODY121 g Housing
The metal body offers a robust choice for industrial mounting and repeated operation.
CDD-11P Technical Specifications
| Parameter | Specification |
|---|---|
| Model | CDD-11P |
| Product Type | Photoelectric sensor |
| Sensing Distance | 10 cm |
| Supply Voltage | 10 to 30 VDC |
| Output | DC three-wire PNP; confirm required NO or NC version before order |
| Housing Material | Metal |
| Housing Color | Silvery |
| Product Series | CDD series |
| Weight | 121 g |
| Listed Body Size | 70 x 18 x 0 mm; confirm installation drawing before order |
Where the CDD-11P Fits Best
Use this model when a PNP output is required for close-range detection in a compact industrial machine layout.
01
Machine Tools
Check workpiece, carrier or fixture presence in machine tool stations.
02
Medical Equipment
Support suitable equipment designs with object presence and position feedback.
03
Automotive Repair
Detect parts and components in repair, testing and service automation fixtures.
04
General Automation
Provide a straightforward PNP signal for industrial presence and position checks.
Selection and Installation Checklist
Match the PNP input circuit
Confirm that the PLC or controller has a compatible sourcing-input circuit. Verify the required signal logic before ordering and wiring.
Confirm the optical application
Provide the target material, surface, color and installation arrangement. XSZ can confirm the appropriate optical configuration for your actual detection task.
Send These Details for Fast Selection
- Target material, size, color and speed
- Required working distance and mounting space
- PLC input type and required NO or NC logic
- Quantity, cable requirement and operating environment
Product Questions
Frequently Asked Questions
01
Can the CDD-11P connect to a PLC?
Yes. Its DC three-wire PNP output is intended for compatible sourcing-input control circuits. Confirm the PLC input type before wiring.
02
Is it available in NO and NC versions?
The reference specification lists normally open and normally closed output logic. State the required logic when requesting a quote so the final configuration can be confirmed.
03
Can XSZ confirm the sensing method?
Yes. Send the target material, working distance and installation arrangement. XSZ can recommend the suitable sensor configuration before order.
04
Can XSZ support OEM orders?
Yes. Send the quantity, cable, labeling and packaging requirements for factory evaluation.
Need Pricing or a CDD-11P Sample?
Send the target, sensing distance, PLC input, required NO or NC logic and order quantity. XSZ will confirm the configuration before quotation.
